| Brand Name: | FUTAO |
| Model Number: | JBB-1 to JBB-3 |
| MOQ: | 10 टुकड़े |
| कीमत: | $1 - $9 |
| Delivery Time: | 30 कार्यदिवस |
| Payment Terms: | एल/सी, टी/टी |
JBB Type Parallel Groove Clamp for Steel Wire pole accessories
JBB type parallel groove clamp for steel wire is adopted hot dip galvanized steel as raw material for production, and it is equipped two bolts, generally suitable for non-sustainable tension connection with middle & small section steel stranded conductor on overhead lightening conductor; on the other hand, it is also applicable for jumping line connection of non straight pole & tower. Based on different materials, parallel groove clamps are made up of iron, aluminum, copper and so on.
JBB Type Parallel Groove Clamp for Steel Wire
| Type | Applicable Steel Stranded Wire Section Area (mm2) | Dimension (mm) | Bolt Quantity | Weight (kg) | ||||
| B | M | L | R | H | ||||
| JBB-1 | 6.6~7.8 | 44 | 12 | 90 | 4.5 | 50 | 2 | 0.62 |
| JBB-2 | 9.6~11.0 | 50 | 16 | 90 | 6.0 | 60 | 2 | 0.82 |
| JBB-3 | 13.0~14.0 | 56 | 16 | 124 | 7.0 | 65 | 3 | 1.90 |
